MASTERYS BC (15-80 kVA)
Reliable, simple and ready-to-use power protection
(MC) ED 079 909 EC 052 323 Sieget, Gerald M. Three Approaches to Speech. Inservicc training is reported as continuous, with instruction in the classroom led.
The solution for
- Data servers
- Telecommunications
- Service sector
Advantages
A complete, cost-effective solution
- Online double conversion mode with an output power factor of 0.9 providing 12% more active power compare to UPS with a power factor of 0.8
- Dual input mains allows you to manage independent power sources
- Increased system availability placing two UPS in parallel for 1+1 redundancy
- Internal manual bypass for easy maintenance without power interruption
- Internal batteries providing more than 1 hour runtime
- Multilanguage display
Tailored to your environment
- Saves space with a reduced footprint and optimized cabinet size
- Low noise level
- Flexible battery solutions
- Compact, lightweight and easy to install
- Extended battery life and performance with exclusive EBS battery charging management for increased battery life
MASTERYS BC (100-120 kVA)
Reliable, simple and ready-to-use power protection
The solution for
- Server rooms
- Service Sector
- Infrastructure
- Healthcare Sector
- Light industrial applications
Advantages
A complete, cost-effective solution
- Online double conversion mode with an output power factor of 0.9 providing 12% more active power compare to UPS with a power factor of 0.8
- Dual input mains allows you to manage independent power sources
- Increased system availability placing two UPS in parallel for 1+1 redundancy
- Internal manual bypass for easy maintenance without power interruption
- Multilanguage display
Tailored to your environment
- Saves space with a reduced footprint and optimized cabinet size
- Low noise level
- Flexible battery solutions
- Compact, lightweight and easy to install
- Extended battery life and performance with exclusive EBS battery charging management for increased battery life
MASTERYS BC (15-80 kVA)
Standard electrical features
- Dual input mains (10-40 kVA)
- Internal maintanance bypass
- Backfeed protection: detection circuit
- EBS (Expert Battery System) for battery management
Electrical options
- External battery cabinet
- External temperature sensor
- Additional battery chargers
- Galvanic isolation transformer
- Parallel kit
- ACS synchronization system
Standard communication features
- MODBUS RTU
- 2 slots for communication options
Communication options
- Dry-contact interface
- Remote mimic panel
- PROFIBUS
- NET VISION: professional WEB/SNM interface for UPS monitoring and shutdown management of several operating systems
Remote monitoring service
- LINK-UPS, remote monitoring service that connects your UPS to your Critical Power specialist 24/7
MASTERYS BC (100-120 kVA)
Standard electrical features
- Dual input mains
- Internal manual bypass
- Backfeed protection: detection circuit
- EBS (Expert Battery System) for battery management
Electrical options
- External battery cabinet
- External temperature sensor
- Additional battery chargers
- Galvanic isolation transformer
- Parallel kit
- ACS synchronization system
Standard communication features
- MODBUS RTU
- 2 slots for communication options
Communication options
- Dry-contact interface
- MODBUS TCP
- PROFIBUS
- NET VISION: professional WEB/SNMP interface for UPS monitoring and shutdown management of several operating systems
Remote monitoring service
- LINK-UPS, remote monitoring service that connects your UPS to your Critical Power specialist 24/7
MASTERYS BC (15-80 kVA)
UPS and internal batteries
Cabinet type S height 800 mm
Cabinet type M height 1000 mm
Cabinet type T height 1400 mm
Technical data
| Sn [kVA] | 15 | 20 | 30 | 40 | 60 | 80 | | Pn [kW] | 13.5 | 18 | 27 | 36 | 54 | 72 | | Input / output 3/1 | • | • | - | - | - | - | | Input / output 3/3 | • | • | • | • | • | • | | Parallel configuration | 1+1 (1) |
| INPUT |
|---|
| Rated voltage | 400 V (3ph + N) | | Voltage tolerances | 240 V to 480 V(2) | | Rated frequency | 50/60 Hz ± 10% | | Power factor / THDI | 0.99 / < 3% |
| OUTPUT |
|---|
| Rated voltage | 1ph + N: 230 V (can be configured 220/240 V)
3ph + N: 400 V (can be configured 380/415 V) | | Voltage tolerance | static load ±1% dynamic load in accordance with VFI-SS-111 | | Rated frequency | 50/60 Hz | | Frequency tolerance | ± 2% (configurable from 1% to 8%) | | Overload | 125% for 10 minutes, 150% for 1 minute | | Crest factor | 3:1 |
| BYPASS |
|---|
| Rated voltage | rated output voltage | | Voltage tolerance | ± 15% (configurable with from 10% to 20%) | | Rated frequency | 50/60 Hz | | Frequency tolerance | ± 2% (configurable for Genset compatibility) |
| EFFICIENCY |
|---|
| Online mode @ 100 % of load | up to 94.5% |
| ENVIRONMENT |
|---|
| Operating ambient temperature | from 0 °C up to 40(2) °C (from 15 °C to 25 °C for maximum battery life) | | Relative humidity | 0% - 95% without condensation | | Maximum altitude | 1000 m without derating (max. 3000 m) | Acoustic level at 1 m
(ISO 3746) | < 52 dBA | < 55 dBA | < 62 dBA |
| UPS CABINET |
|---|
| Dimensions W x D x H | 444 x 795 x 800 / 1000 / 1400 mm | 444 x 795 x 1400 mm | | Weight | 105 kg(3) | 110 kg(3) | 135 kg(3) | 152 kg(3) | 180 kg(3) | 200 kg(3) | | Degree of protection | IP20 | | Colours | RAL 7012 |
| STANDARDS |
|---|
| Safety | IEC/EN 62040-1 (TÜV SÜD certified), EN 60950-1, AS 62040.1.1, AS 62040.1.2 | | EMC | IEC/EN 62040-2, AS 62040.2 | | Performance | VFI-SS-111 - IEC/EN 62040-3, AS 62040.3 | | Product declaration | CE, RCM (E2376) |
|
(1) The standard model is prepared for a 1+1 redundant system. Upon request, it is possible to have connected up to 6 modules in a parallel system.
(2) Conditions apply.
(3) Without batteries. Descargar manual de real basic array.
MASTERYS BC (100-120 kVA)
Technical data
| Sn [kVA] | 100 | 120 | | Pn [kW] | 90 | 108 | | Input / output 3/3 | • | • | | Parallel configuration | 1+1 (1) |
| INPUT |
|---|
| Rated voltage | 400 V 3ph + N | | Voltage tolerances | 240 V to 480 V(2) | | Rated frequency | 50/60 Hz ± 10% | | Power factor / THDI | 0.99 / < 3% |
| OUTPUT |
|---|
| Rated voltage | 400 V (can be configured 380/415 V) | | Voltage tolerance | static load ±1% dynamic load in accordance with VFI-SS-111 | | Rated frequency | 50/60 Hz | | Frequency tolerance | ± 2% (configurable from 1% to 8%) | | Overload | 125% for 10 minutes, 150% for 1 minute | | Crest factor | 3:1 |
| BYPASS |
|---|
| Rated voltage | rated output voltage | | Voltage tolerance | ± 15% (configurable with from 10% to 20%) | | Rated frequency | 50/60 Hz | | Frequency tolerance | ± 2% (configurable for Genset compatibility) |
| EFFICIENCY |
|---|
| Online mode @ 100 % of load | up to 94.5% |
| ENVIRONMENT |
|---|
| Operating ambient temperature | from 0 °C up to 40(2) °C (from 15 °C to 25 °C for maximum battery life) | | Relative humidity | 0% - 95% without condensation | | Maximum altitude | 1000 m without derating (max. 3000 m) | Acoustic level at 1 m
(ISO 3746) | < 65 dBA |
| UPS CABINET |
|---|
| Dimensions W x D x H | 700 x 800 x 1930 mm | | Weight | 410 kg | 430 kg | | Degree of protection | IP20 | | Colours | RAL 7012 |
| STANDARDS |
|---|
| Safety | IEC/EN 62040-1 (TÜV SÜD certified), EN 60950-1, AS 62040.1.1, AS 62040.1.2 | | EMC | IEC/EN 62040-2, AS 62040.2 | | Performance | VFI-SS-111 - IEC/EN 62040-3, AS 62040.3 | | Product declaration | CE, RCM (E2376) |
|
(1) The standard model is prepared for a 1+1 redundant system. Upon request, it is possible to have connected up to 6 modules in a parallel system.
(2) Conditions apply.
